Simpson Strong-Tie LTB LTB20 Light Tension Bridging, 20 in L, 2 x 8, 2 x 10 in Post/Joist, Steel, Galvanized

Category Joist Hangers
NB NB
NB NB
Call for price
Starting from
$1.06 / EACH
/
- +
Your Pick Up location is (Click to switch) Hillsdale, Hillsdale

Simpson Strong-Tie LTB LTB20 Light Tension Bridging, 20 in L, 2 x 8, 2 x 10 in Post/Joist, Steel, Galvanized

Item Code: NB
Category Joist Hangers
Manufacturer Simpson Strong-Tie
  • Keeps floor system continuity and prevents joist rotation
  • LTB works only in tension, so must be used in cross pairs
  • Galvanized (G90) for extra corrosion resistance
  • Installation flexibility, with multiple fastener holes on each end in a staggered pattern
  • Can be utilized with 6 and 8 in joists at 12 in O.C

Description

The LTB provides bracing between floor joists as a critical contribution to the structural strength of a floor. Installed in pairs, this light tension-type bridging keeps joists in place and prevents them from rotating while distributing loads over more than one joist. The LTB features a staggered nail pattern to accommodate 2 x 8 and 2 x 10 joists and is designed for maximum nailing flexibility, with the option to use as few as two nail holes on each end and as many as six.

Specifications

Weight

0.13lb

Height

0.25in

Width

19.5in

Length

0.75in

Brand

Simpson Strong-Tie

Category

Joist Hangers

Manufacturer

Simpson Strong-Tie

Description

The LTB provides bracing between floor joists as a critical contribution to the structural strength of a floor. Installed in pairs, this light tension-type bridging keeps joists in place and prevents them from rotating while distributing loads over more than one joist. The LTB features a staggered nail pattern to accommodate 2 x 8 and 2 x 10 joists and is designed for maximum nailing flexibility, with the option to use as few as two nail holes on each end and as many as six.
